Lip Sync using Wan 2.2 (S2V)

Video Lecture

Section	Video Links
Wan 2.2 S2V Lip Sync

Description

We will use the GGUF quantised Wan2.2 models.

• umt5-xxl-encoder-Q8_0.gguf (6.04 GB)
• high_noise_model.safetensors (1.23 GB) ⇾ rename to Wan2.2-I2V-A14B-lora-high_noise.safetensors
• wav2vec2_large_english_fp16.safetensors (631 MB)
• Wan2.2-S2V-14B-Q8_0.gguf (19.6 GB)
• wan2.1_vae.safetensors (254 MB)

📂 ComfyUI/
├── 📂 models/
│   ├── 📂 clip/
│   │   └── umt5-xxl-encoder-Q8_0.gguf
│   ├── 📂 loras/
│   │   ├── Wan2.2-I2V-A14B-lora-high_noise.safetensors
│   ├── 📂 audio_encoders/
│   │   └── wav2vec2_large_english_fp16.safetensors
│   ├── 📂 unet/
│   │   └── Wan2.2-S2V-14B-Q8_0.gguf
│   └── 📂 vae/
│       └── wan2.1_vae.safetensors

Sample Workflows

For S2V workflow use the WanSoundImageToVideo and WanSoundImageToVideoExtend nodes.

Download Example Audio (woman) and save into your ComfyUI/input/ folder.

Initial Image	Input Video	Workflow

WGET Commands

If you are using Runpod, or a similar hosted GPU service, then you can access your running pod/instance using a terminal.

# CD into ./ComfyUI/models/clip/ folder
wget -c https://huggingface.co/city96/umt5-xxl-encoder-gguf/resolve/main/umt5-xxl-encoder-Q8_0.gguf

# CD into ./ComfyUI/models/loras/ folder
wget https://huggingface.co/lightx2v/Wan2.2-Lightning/resolve/main/Wan2.2-I2V-A14B-4steps-lora-rank64-Seko-V1/high_noise_model.safetensors -O Wan2.2-I2V-A14B-lora-high_noise.safetensors

# CD into ./ComfyUI/models/audio_encoders/ folder # Create if you can't find this folder
wget -c https://huggingface.co/Comfy-Org/Wan_2.2_ComfyUI_Repackaged/resolve/main/split_files/audio_encoders/wav2vec2_large_english_fp16.safetensors

# CD into ./ComfyUI/models/unet/ folder
wget -c https://huggingface.co/QuantStack/Wan2.2-S2V-14B-GGUF/resolve/main/Wan2.2-S2V-14B-Q8_0.gguf

# CD into ./ComfyUI/models/vae/ folder
wget -c https://huggingface.co/Comfy-Org/Wan_2.1_ComfyUI_repackaged/resolve/main/split_files/vae/wan_2.1_vae.safetensors

Wait for files to download fully before running your workflows.

Troubleshooting

Error : Input type (float) and bias type (c10::Half) should be the same

The problem is a dtype mismatch.

We can hard patch the ComfyUI audio encoder script. Open:

ComfyUI/comfy/audio_encoders/audio_encoders.py

Find:

out, all_layers = self.model(audio.to(self.load_device))

Change to:

self.model = self.model.to(self.load_device)

# Match input dtype to model dtype
audio = audio.to(self.load_device, dtype=next(self.model.parameters()).dtype)

out, all_layers = self.model(audio)

Warning

Indent using the Space key, not the Tab key.

-        out, all_layers = self.model(audio.to(self.load_device))
+        self.model = self.model.to(self.load_device)
+
+        # Match input dtype to model dtype
+        audio = audio.to(self.load_device, dtype=next(self.model.parameters()).dtype)
+
+        out, all_layers = self.model(audio)
